California Air Tools Ultra Quiet, Oil-Free and Powerful 10020CHAD Air Compressor with Automatic Drain

SKU: CAT-TA-10020CHAD
  • 2.0 HP (Rated/Running)
  • 10 Gallon Steel Horizontal Air Tank
  • 6.40 CFM @ 40 PSI
  • 5.30 CFM @ 90 PSI
Unit Price
Quantity
Subtotal
US 551.00$
US 551.00$
Congratulations! You got a great price!
Add to cart Added
Checkout
Options
Barcode
850004451335
Description

The CALIFORNIA AIR TOOLS 10020CHAD Ultra Quiet & Oil-Free Air Compressor is designed to be one of the quietest 2.0 Hp air compressors in the industry having only 70 decibels of sound.


The Powerful 2.0 HP motor operates at only 1680 RPM creating less noise and less wear.


The SP Series of Ultra Quiet Air Compressor Motors have been designed to increase duty cycle and allow for longer continuous run times.
The Oil-Free Dual Piston Pump System is engineered for high performance and durability.


The CAT-10020CHAD Air Compressor has a Oil-Free Dual Piston pump designed to have a life cycle before wear of 3000 Plus hours compared to other comparable air compressors with life cycles of 500 hours or less.


The Oil-Free pump allows for use in a variety of temperatures (cold starts) and uneven terrains (no oil in the pump).


The Easy Start Valve feature allows for a easier start up using less starting amps.


The Easy Start Valve releases a small amount of air from the pump at start up to produce a no-load condition allowing the motor to spin freely. This no-load start up requires less amps for a easier start up in cold temperatures.


The large low profile 10 Gallon Steel Horizontal Air Tank makes storing under a bench, desk or shelf very easy.


The factory instaled California Air Tools EZ-1 Automatic Drain Valve has been designed to eliminate manually draining your air compressor air tank. The manually set timer allows you to set the time for both the frequency and duration of the draining process.


The 10020CHAD is designed for the person looking for Power, Air Flow, Less Service and Maintenance with at Least 30% Less Noise!




Features:

  • Ultra Quiet - Only 70 decibels
  • Oil-Free Pump – Cleaner air for better tool operation.
    Less maintenance and Costs.
  • Two pressure control gauges
  • One - Industrial 1/4″ female quick connector
  • Easy Start Valve - For Less Starting Amperage
  • Condor Pressure Switch
  • Thermal Overload Protector
  • 125 PSI Maximum Pressure
  • 110v / 60 hz
  • Low Amp Draw - 14 Amps
  • Dedicated 15 amp outlet -14 gauge 25ft cord - Min. 5500 Watt Generator
  • Time to fill tank from empty to full - 120 Seconds
  • Recovery time from 95 PSI to 125 PSI - 25 Seconds
  • Duty Cycle - 70/30
  • Maximum continuous running 30-60 min. (Depending PSI & CFM)
  • Less heat which dissipates more efficiently
  • 10 Gal.Steel (Low Profile) Horzizontal Air Tank
  • EZ-1-2321 Auto Drain Valve Factory Installed
  • L (19") x W/D (15") x H (26.5")
  • 75 lbs
  • 1 Year Limited Warranty
  • Comes complete Two Air Filters
  • Assembled in USA with global components
  • Commerical Use: Refer to State & City Codes
